Volvo

BM L150

Wheel Loader

Operating Weight
45,500 lb
Bucket Capacity - heaped
4.60 yd³
Gross Power
245.0 hp
Net Power
231.0 hp
All wheel loaders
Volvo BM L150 Wheel Loader
1 / 5
Image 1 of 5
Image: volvoce.com

Specifications

43 data points

Operating Specifications

Operating Specifications specifications
Operating Weight45,500 lb
Fuel Capacity89.6 gal
Tire Size23.5-25
Hydraulic System Fluid Capacity43.6 gal
Static Tipping Weight33,158 lb
Operating Voltage24 V
Engine Oil Fluid Capacity7.7 gal
Rear Axle Oscillation30 °
Alternator Supplied Amperage60 A
Front Axle/Diff Fluid Capacity12.5 gal
Rear Axle/Diff Fluid Capacity11.9 gal
Cooling System Fluid Capacity17.2 gal
Transmission Fluid Capacity11.9 gal

Engine

Engine specifications
Engine ModelTD 102
Displacement586 in³
Power Measured @2,100 rpm
Gross Power245.0 hp
Net Power231.0 hp
Number of Cylinders6
Aspirationturbocharged
Torque Measured @1,200 rpm

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity82.8 gal/min
Raise Time6.7 s
Lower Time3.2 s
Dump Time1.9 s
Relief Valve Setting3,046 psi
Pump Typeopen center system

Dimensions

Dimensions specifications
Ground Clearance17 in
Height - Top of Cab138 in
Wheelbase141 in
Width Over Tires110 in
Reach at Max Lift and Dump46 in
Length with Bucket on Ground317 in
Hinge Pin - Max Height169 in

Transmission

Transmission specifications
Max Speed - Forward21.3 mph
Max Speed - Reverse14.7 mph
Transmission Typepowershift
Number of Forward Gears4
Number of Reverse Gears3

Bucket

Bucket specifications
Bucket Capacity - heaped4.60 yd³
Dump Clearance at Max Raise124 in
Breakout Force44,200 lb
Bucket Width126 in
