Volvo
BM L180
- Operating Weight
- 62,800 lb
- Bucket Capacity - heaped
- 6.30 yd³
- Gross Power
- 289.0 hp
- Net Power
- 275.0 hp
1 / 5
Image 1 of 5
Specifications
43 data points
Operating Specifications
| Operating Weight | 62,800 lb |
|---|---|
| Fuel Capacity | 89.6 gal |
| Tire Size | 26.5-25 |
| Hydraulic System Fluid Capacity | 68.7 gal |
| Static Tipping Weight | 38,383 lb |
| Operating Voltage | 24 V |
| Engine Oil Fluid Capacity | 8.8 gal |
| Rear Axle Oscillation | 30 ° |
| Alternator Supplied Amperage | 60 A |
| Front Axle/Diff Fluid Capacity | 12.2 gal |
| Rear Axle/Diff Fluid Capacity | 12.2 gal |
| Cooling System Fluid Capacity | 21.2 gal |
| Transmission Fluid Capacity | 12.7 gal |
Engine
| Engine Model | TD 122 |
|---|---|
| Displacement | 732 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 289.0 hp |
| Net Power | 275.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,100 rpm |
Hydraulic System
| Pump Flow Capacity | 82.8 gal/min |
|---|---|
| Raise Time | 6.6 s |
| Lower Time | 3.5 s |
| Dump Time | 2.5 s |
| Relief Valve Setting | 3,362 psi |
| Pump Type | open center system |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 141 in |
| Wheelbase | 141 in |
| Width Over Tires | 117 in |
| Reach at Max Lift and Dump | 53 in |
| Length with Bucket on Ground | 341 in |
| Hinge Pin - Max Height | 176 in |
Transmission
| Max Speed - Forward | 21.9 mph |
|---|---|
| Max Speed - Reverse | 15.0 mph |
| Transmission Type | powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 6.30 yd³ |
|---|---|
| Dump Clearance at Max Raise | 121 in |
| Breakout Force | 40,690 lb |
| Bucket Width | 126 in |
