Volvo
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
17 data points
General Specifications
| Gross power | 260.0 hp |
|---|---|
| Operating Weight lbs (kg) | 67,380 - 71,410 (30,560 - 32,380 ) Starting 2025 Model Year |
| Operating Weight | 68,020.00 lbs (30,853.39 kg) |
| Bucket Capacity | 1.98 cu yd |
| Max Digging Depth | 24.10 ft (7.35 m) |
| Digging Depth ft (m) | 24.1 (7.4) Starting 2025 Model Year |
| Digging Reach ft. (m) | 35.2 (10.7) Starting 2025 Model Year |
| Engine hp (kW) | 253 (189) Starting 2025 Model Year |
| Breakout force, ISO 6015 (Boost) | 48,069 lb-ft |
| Breakout force, ISO 6015 (Normal) | 44,199 lb-ft |
| Engine speed at max engine torque | 1,600 rpm |
| Lifting capacity, along undercarriage | 19,158 lb |
| Max digging reach | 422 in |
| Overall width | 133 in |
| Tail swing radius | 124 in |
| Tearout force, ISO 6015 (Boost) | 33,630 lb-ft |
| Tearout force, ISO 6015 (Normal) | 30,900 lb-ft |
