Volvo
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Fuel Capacity | 23.8 gal |
|---|---|
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 55 A |
Engine
| Power Measured @ | 2,100 rpm |
|---|---|
| Gross Power | 52.0 hp |
| Number of Cylinders | 4 |
| Aspiration | natural |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 101 in |
| Tail Swing Radius | 66 in |
| Width to Outside of Tracks | 76 in |
| Removal Counterweight Clearance | 28 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 60 in |
| Number of Track Rollers per Side | 5 |
| Shoe Size | 16 in |
| Number of Carrier Rollers per Side | 1 |
Boom/Stick Excavator Option 1
| Max Reach Along Ground | 236 in |
|---|---|
| Max Loading Height | 162 in |
| Max Vertical Wall Digging Depth | 103 in |
| Max Cutting Height | 228 in |
| Shipping Length of Unit | 233 in |
| Shipping Height of Unit | 101 in |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.41 yd³ |
| Minimum Bucket Capacity | 0.10 yd³ |
Boom/Stick Excavator Option 2
| Max Vertical Wall Digging Depth | 119 in |
|---|---|
| Max Cutting Height | 238 in |
| Max Loading Height | 170 in |
| Max Reach Along Ground | 250 in |
| Shipping Length of Unit | 233 in |
| Shipping Height of Unit | 101 in |
