Volvo
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
57 data points
Operating Specifications
| Fuel Capacity | 21.2 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 27.1 gal/min |
| Hydraulic System Fluid Capacity | 18.5 gal |
| Hydraulic System Relief Valve Pressure | 3,626 psi |
| Engine Oil Capacity | 2.2 gal |
| Cooling System Fluid Capacity | 2.2 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 55 A |
| Hydraulic Pump Type | gear pump |
| Tire Size | 12x18 |
Engine
| Displacement | 135 in³ |
|---|---|
| Power Measured @ | 2,500 rpm |
| Net Power | 45.2 hp |
| Torque Measured @ | 2,050 rpm |
| Net Torque | 103 lb-ft |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 114 in |
| Wheelbase | 81 in |
| Overall Width | 7 in |
| Tail Swing Radius | 59 in |
| Upper Structure Clearance | 41 in |
Transmission
| Max Travel Speed | 11.2 mph |
|---|---|
| Transmission Type | hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.41 yd³ |
| Minimum Bucket Capacity | 0.10 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 124 in |
|---|---|
| Max Cutting Height | 215 in |
| Max Reach Along Ground | 215 in |
| Max Loading Height | 157 in |
| Shipping Length of Unit | 209 in |
| Shipping Height of Unit | 114 in |
| Max Vertical Wall Dig Depth | 80 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 139 in |
|---|---|
| Max Cutting Height | 223 in |
| Max Reach Along Ground | 230 in |
| Max Loading Height | 166 in |
| Shipping Height of Unit | 114 in |
| Shipping Length of Unit | 209 in |
| Max Vertical Wall Dig Depth | 95 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 124 in |
|---|---|
| Max Cutting Height | 259 in |
| Max Reach Along Ground | 233 in |
| Max Loading Height | 226 in |
| Shipping Height of Unit | 114 in |
| Shipping Length of Unit | 152 in |
| Max Vertical Wall Dig Depth | 118 in |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 139 in |
|---|---|
| Max Cutting Height | 272 in |
| Max Reach Along Ground | 248 in |
| Max Loading Height | 206 in |
| Shipping Height of Unit | 114 in |
| Shipping Length of Unit | 152 in |
| Max Vertical Wall Dig Depth | 121 in |
