Volvo
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 8,430 lb |
|---|---|
| Max Speed | 6.8 mph |
| Fuel Capacity | 27.3 gal |
| Hydraulic System Fluid Capacity | 15.9 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 A |
| Engine Oil Fluid Capacity | 4.0 gal |
| Cooling System Fluid Capacity | 4.1 gal |
Engine
| Engine Model | TC63 |
|---|---|
| Displacement | 268 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 92.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,800 rpm |
| Max Torque | 301 lb-ft |
Hydraulic System
| Pump Flow Capacity | 23.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,335 psi |
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Height - Top of Cab | 83 in |
| Wheelbase | 49 in |
| Width Over Tires | 73 in |
| Reach at Max Lift and Dump | 36 in |
| Length with Bucket | 150 in |
| Clearance at Max Lift and Dump | 97 in |
| Turning Radius from Center - inc bucket | 69 in |
| Turning Radius from Center - machine rear | 69 in |
| Length w/o Bucket | 108 in |
General Specifications
| Engine Power HP (KW) | 92 (66.9) Starting 2016 Model Year |
|---|---|
| Operating Width IN. (CM) | 72 (183) Starting 2016 Model Year |
| OPERATING LOAD LBS. (KG) | 3,000 (1,360.7) Starting 2016 Model Year |
Loader
| Bucket Capacity | 0.90 yd³ |
|---|---|
| Operating Load Rating | 3,000 lb |
| Tipping Angle | 6,024 ° |
| Operating Width | 72 in |
| Bucket Width | 78 in |
