VolvoVolvo
MC85C
Skid Steer Loader
66 specifications
1 / 5
Image 1 of 5
Specifications
64 data points
Engine
| Engine Model | TCAE-55 |
|---|---|
| Displacement | 269 in³ |
| Gross Power | 72.5 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbo |
| Max Torque | 295 lb-ft |
| Fuel Type | Diesel |
| Alternator | 342,000 A |
| Battery | 12/109 |
| Starter | 5.7 hp |
| Gross horsepower - SAE J1995 | 73.8 hp |
Weights
| Weight | 9,288 lb |
|---|
Dimensions
| Ground Clearance | 10 in |
|---|---|
| Wheelbase | 50 in |
| Overall Height | 83 in |
| Turning Radius | 70 in |
| Dump Height | 91 in |
| Dump angle | 42 ° |
| Angle of departure | 29 ° |
| Height to Hinge Pin | 126 in |
| Overall length (W/bucket) | 150 in |
| Overall length (L/bucket) | 119 in |
| Turning radius front L/bucket | 60 in |
| Turning radius front W/bucket | 91 in |
Fluid Capacities
| Fuel Tank | 27.3 gal |
|---|---|
| Hydraulic system | 14.6 gal |
| Cooling system | 5.9 gal |
| Engine oil w/ filter change | 4.0 gal |
| Hydraulic oil reservoir | 6.9 gal |
| Tipping Load | 6,369 lb |
Bucket
| Breakout force, lift | 6,056 lb |
|---|---|
| Landscape Bucket Width | 85 in |
| Breakout force, curl | 6,543 lb |
| General Purpose Bucket Heaped | 0.71 yd³ |
| General Purpose Bucket Height | 22 in |
| General Purpose Bucket Length | 32 in |
| General Purpose Bucket Weight | 575 lb |
| General Purpose Bucket Width | 85 in |
| Landscape Bucket Heaped cap | 0.90 yd³ |
| Landscape Bucket Height | 22 in |
| Landscape Bucket Length | 39 in |
| Landscape Bucket Weight | 0 in³ |
| Multi Purpose Bucket Heaped cap | 0.90 yd³ |
| Multi Purpose Bucket Height | 28 in |
| Multi Purpose Bucket Length | 39 in |
| Multi Purpose Bucket Weight | 884 lb |
| Multi Purpose Bucket Width | 85 in |
General Specifications
| Engine Power HP (KW) | 74 (55) Starting 2019 Model Year |
|---|---|
| Operating Width IN. (CM) | 71 (180.3) Starting 2019 Model Year |
| Rated Operating Capacity LBS (KG) 50% | 3,186 (1,445) Starting 2019 Model Year |
Loader
| Operating Load Rating | 3,186 lb |
|---|---|
| Operating Width | 73 in |
| Bucket Width | 75 in |
| Standard hydraulic pump output | 23.8 gal/min |
| System pressure | 3,336 psi |
| High flow pump output | 33.1 gal/min |
Performance
| Curl | 1.8 s |
|---|---|
| Dump | 2.1 s |
| Lift arm path | Vertical |
| Lower (power down) | 2.5 s |
| Raise (lifting) | 3.7 s |
| Rated operating capacity (ISO 14397) | 1,445 lb |
Speeds
| Single speed | 6.8 mph |
|---|---|
| Two speed | 12.4 mph |
