Volvo
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 5,902 lb |
|---|---|
| Max Speed | 6.9 mph |
| Fuel Capacity | 17.5 gal |
| Hydraulic System Fluid Capacity | 9.6 gal |
| Tire Size | 10.00x16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 45 A |
| Engine Oil Fluid Capacity | 2.3 gal |
| Cooling System Fluid Capacity | 4.0 gal |
| Chain Box Fluid Capacity - each side | 1.6 gal |
| Operating Speed | 6.9 mph |
Engine
| Engine Model | V2003-TB |
|---|---|
| Displacement | 122 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 60.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
Hydraulic System
| Pump Flow Capacity | 30.6 gal/min |
|---|---|
| Relief Valve Pressure | 2,500 psi |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 78 in |
| Wheelbase | 41 in |
| Width Over Tires | 66 in |
| Reach at Max Lift and Dump | 27 in |
| Length with Bucket | 134 in |
| Clearance at Max Lift and Dump | 85 in |
| Length w/o Bucket | 103 in |
Loader
| Bucket Capacity | 0.60 yd³ |
|---|---|
| Operating Load Rating | 1,500 lb |
| Tipping Angle | 3,000 ° |
