Volvo
Wacker Neuson
WL18
Wheel Loader
22 specifications
Volvo
ZL302C
- Operating Weight
- 4,630 lb
- Bucket Capacity - heaped
- 0.41 yd³
- Gross Power
- 31.0 hp
- Net Power
- 30.0 hp
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Operating Weight | 4,630 lb |
|---|---|
| Fuel Capacity | 10.1 gal |
| Tire Size | 10.0/75-15.3 |
| Hydraulic System Fluid Capacity | 7.4 gal |
| Static Tipping Weight | 3,197 lb |
| Operating Voltage | 12 V |
| Turning Radius | 111 in |
| Engine Oil Fluid Capacity | 1.2 gal |
| Rear Axle Oscillation | 20 ° |
| Alternator Supplied Amperage | 65 A |
| Front Axle/Diff Fluid Capacity | 1.4 gal |
| Rear Axle/Diff Fluid Capacity | 1.6 gal |
Engine
| Engine Model | F 4 M 1008F |
|---|---|
| Displacement | 84 in³ |
| Power Measured @ | 3,000 rpm |
| Gross Power | 31.0 hp |
| Net Power | 30.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Natural |
| Torque Measured @ | 2,000 rpm |
Hydraulic System
| Pump Flow Capacity | 8.0 gal/min |
|---|---|
| Raise Time | 5.0 s |
| Lower Time | 3.0 s |
| Dump Time | 1.5 s |
| Relief Valve Setting | 3,046 psi |
| Pump Type | gear type pump |
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Height - Top of Cab | 91 in |
| Wheelbase | 60 in |
| Width Over Tires | 52 in |
| Reach at Max Lift and Dump | 18 in |
| Length with Bucket on Ground | 155 in |
| Hinge Pin - Max Height | 115 in |
Transmission
| Max Speed - Forward | 12.5 mph |
|---|---|
| Max Speed - Reverse | 12.5 mph |
| Transmission Type | hydrostatic |
| Number of Forward Gears | 1 |
| Number of Reverse Gears | 1 |
Bucket
| Bucket Capacity - heaped | 0.41 yd³ |
|---|---|
| Dump Clearance at Max Raise | 93 in |
| Bucket Width | 40 in |
