Wacker Neuson
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 6,437 lb |
|---|---|
| Max Speed | 12.0 mph |
| Fuel Capacity | 30.0 gal |
| Hydraulic System Fluid Capacity | 2.9 gal |
| Tire Size | 10 x 16.5 |
Engine
| Engine Model | KDI 1903 TCR |
|---|---|
| Displacement | 114 in³ |
| Power Measured @ | 2,750 rpm |
| Gross Power | 56.0 hp |
| Engine Make | Kohler |
Hydraulic System
| Pump Flow Capacity | 20.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,500 psi |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 81 in |
| Wheelbase | 44 in |
| Width Over Tires | 66 in |
| Reach at Max Lift and Dump | 38 in |
| Length with Bucket | 135 in |
| Clearance at Max Lift and Dump | 97 in |
| Length w/o Bucket | 107 in |
General Specifications
| Engine Power HP (KW) | 56 (42) Starting 2019 Model Year |
|---|---|
| Operating Width IN. (CM) | 65.9 (167) Starting 2019 Model Year |
| OPERATING LOAD LBS. (KG) | 2,000 (907) Starting 2017 Model Year |
| Rated Operating Capacity LBS (KG) 50% | 2,000 (907) Starting 2019 Model Year |
Loader
| Operating Load Rating | 2,000 lb |
|---|---|
| Operating Width | 66 in |
| bucket breakout force (ISO 14397) | 5,300 lb |
| Boom breakout force | 5,000 lb |
