Wacker Neuson
TCM
L3-2
Wheel Loader
16 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 6,856 lb |
|---|---|
| Fuel Capacity | 14.1 gal |
| Hydraulic System Fluid Capacity | 8.5 gal |
| Static Tipping Weight | 4,438 lb |
| Turning Radius | 124 in |
| Rear Axle Oscillation | 24 ° |
Engine
| Engine Model | 404 C-22 |
|---|---|
| Gross Power | 48.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 13.0 gal/min |
|---|---|
| Relief Valve Setting | 3,045 psi |
| Pump Type | Gear pump |
Dimensions
| Height - Top of Cab | 89 in |
|---|---|
| Wheelbase | 69 in |
| Width Over Tires | 54 in |
| Length with Bucket on Ground | 180 in |
| Hinge Pin - Max Height | 127 in |
Transmission
| Max Speed - Forward | 12.4 mph |
|---|---|
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 2 |
Bucket
| Bucket Capacity - heaped | 0.60 yd³ |
|---|---|
| Dump Clearance at Max Raise | 96 in |
| Breakout Force | 9,089 lb |
