YanmarYanmar
AW695K
Combine
16 specifications
Yanmar
AW850
- Operating Weight w/o Attachment
- 9,502 lb
- Fuel Capacity
- 29.1 gal
- Displacement
- 203 in³
- Power
- 83.9 hp
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight w/o Attachment | 9,502 lb |
|---|---|
| Fuel Capacity | 29.1 gal |
| Transmission Type | Hydrostatic Transmission |
Engine
| Engine Model | 4TNV98T |
|---|---|
| Displacement | 203 in³ |
| Power Measured @ | 2,400 rpm |
| Number of Cylinders | 4 |
| Aspiration | Turbocharger |
| Power | 83.9 hp |
Dimensions
| Overall Length | 233 in |
|---|---|
| Width Over Tires | 95 in |
| Height to Top of Isomount Cab | 100 in |
Grain Handling
| Grain Tank Capacity | 475.7 gal |
|---|---|
| Unloading Auger Length | 198 in |
Separating
| Separating Area | 2,387 in³ |
|---|
Threshing
| Rotor Diameter | 23 in |
|---|---|
| Rotor Length | 86 in |
| Rotor Speed - High | 710 rpm |
| Rotor Speed - Low | 310 rpm |
| Concave Area | 3,255 in³ |
