Yanmar
Kubota
B2920
Tractor
23 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Tire Size Front - 2wd / 4wd | 23 x 8.5 â?? 12 in |
|---|
Engine
| Displacement | 100 in³ |
|---|---|
| Power Measured @ | 27,500 rpm |
| Gross Power | 31.2 hp |
| Net Power | 30.0 hp |
| Number of Cylinders | 3 |
| PTO Power | 23.5 hp |
| Bore | 4 in |
| Stroke | 4 in |
| Air cleaner | Dual dry |
| Cooling system | Liquid cooled |
| Lubrication | Full pressure |
Hydraulic System
| Pump Flow Capacity | 4.8 gal/min |
|---|---|
| Hydraulic System Type | Open center |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Wheelbase | 782 in |
| Overall Length | 109 in |
| Overall Width | 619 in |
| Weight | 2,030 lb |
Transmission
| Max Speed | 14.8 mph |
|---|---|
| Transmission Type | Synchronized shuttle |
Fluid Capacities
| Fuel Tank | 7.1 gal |
|---|---|
| Engine Oil | 0.9 gal |
| Cooling system | 0.6 gal |
| Transmission | 4.6 gal |
Tires & Wheels
| Rear Tires Size | 14 â?? 17.5 in |
|---|
3-Point Hitch
| Lift capacity @ 24in. (ASAE) | 1,209 lb |
|---|---|
| 3-point hitch | Category 1 |
Power Take-Off (PTO)
| PTO type | Continuous live |
|---|---|
| PTO speed rear | 547 rpm |
