YTO

ZL50G

Wheel Loader

Operating Weight
36,376 lb
Bucket Capacity - heaped
4.00 yd³
Gross Power
217.3 hp
All wheel loaders
YTO ZL50G Wheel Loader
1 / 5
Image 1 of 5
Image: machmall.com

Specifications

20 data points

Operating Specifications

Operating Specifications specifications
Operating Weight36,376 lb
Fuel Capacity58.2 gal
Hydraulic System Fluid Capacity58.2 gal
Static Tipping Weight11,023 lb
Turning Radius233 in

Engine

Engine specifications
Engine ModelWEICHAI WD615 67G3-28
Gross Power217.3 hp
Aspirationturbocharged

Hydraulic System

Hydraulic System specifications
Raise Time5.9 s
Lower Time10.6 s

Dimensions

Dimensions specifications
Height - Top of Cab134 in
Width Over Tires119 in
Reach at Max Lift and Dump47 in
Length with Bucket on Ground289 in

Transmission

Transmission specifications
Max Speed - Forward7.2 mph
Max Speed - Reverse10.0 mph
Number of Forward Gears3
Number of Reverse Gears3

Bucket

Bucket specifications
Bucket Capacity - heaped4.00 yd³
Dump Clearance at Max Raise119 in
