Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Fuel Capacity | 26.5 gal |
|---|---|
| Tire Size | 16/70-24 |
| Hydraulic System Fluid Capacity | 29.1 gal |
| Operating Voltage | 24 V |
| Rear Axle Oscillation | 10 ° |
| Alternator Supplied Amperage | 55 A |
| Engine Oil Capacity | 2.4 gal |
| Front Diff Fluid Capacity | 2.3 gal |
| Rear Diff Fluid Capacity | 3.1 gal |
| Static Tipping Load - Forks | 8,819 lb |
Engine
| Engine Model | KHD BF 4M 1012 E |
|---|---|
| Displacement | 195 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 77.8 hp |
| Net Power | 75.1 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 221 lb-ft |
Hydraulic System
| Pump Flow Capacity | 21.7 gal/min |
|---|---|
| Relief Valve Setting | 3,024 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 111 in |
| Wheelbase | 89 in |
| Max Lift Height | 220 in |
| Fork Tine Length | 40 in |
| Length with out Forks on Ground | 209 in |
Transmission
| Max Speed - Forward | 12.5 mph |
|---|---|
| Max Speed - Reverse | 7.8 mph |
| Transmission Type | full power shift |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
