Zettelmeyer
ZL5002
- Operating Weight
- 51,368 lb
- Bucket Capacity - heaped
- 5.49 yd³
- Gross Power
- 289.7 hp
- Net Power
- 276.3 hp
1 / 5
Image 1 of 5
Specifications
43 data points
Operating Specifications
| Operating Weight | 51,368 lb |
|---|---|
| Fuel Capacity | 95.2 gal |
| Tire Size | 26.5R25 |
| Hydraulic System Fluid Capacity | 60.8 gal |
| Static Tipping Weight | 39,132 lb |
| Operating Voltage | 24 V |
| Turning Radius | 287 in |
| Engine Oil Fluid Capacity | 7.1 gal |
| Rear Axle Oscillation | 24 ° |
| Alternator Supplied Amperage | 65 A |
| Front Axle/Diff Fluid Capacity | 14.3 gal |
| Rear Axle/Diff Fluid Capacity | 13.5 gal |
| Transmission Fluid Capacity | 5.6 gal |
Engine
| Engine Model | LTA 10-C 290 |
|---|---|
| Displacement | 623 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 289.7 hp |
| Net Power | 276.3 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged + aftercooled |
| Torque Measured @ | 1,300 rpm |
Hydraulic System
| Pump Flow Capacity | 78.8 gal/min |
|---|---|
| Raise Time | 6.5 s |
| Lower Time | 4.6 s |
| Dump Time | 1.7 s |
| Relief Valve Setting | 3,626 psi |
| Pump Type | tandem axial piston |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 138 in |
| Wheelbase | 146 in |
| Reach at Max Lift and Dump | 46 in |
| Length with Bucket on Ground | 348 in |
| Hinge Pin - Max Height | 175 in |
Transmission
| Max Speed - Forward | 23.7 mph |
|---|---|
| Max Speed - Reverse | 15.6 mph |
| Transmission Type | full powershift countershaft |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 5.49 yd³ |
|---|---|
| Bucket Capacity - struck | 4.80 yd³ |
| Dump Clearance at Max Raise | 127 in |
| Breakout Force | 54,404 lb |
| Bucket Width | 119 in |
