Agco
Fendt
817
Tractor
23 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 14,793 lb |
|---|---|
| Fuel Capacity | 26.5 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 14,283 lb |
| 3 Point Hitch Type | Category II-IIIN |
| Alternator Supplied Amperage | 150 A |
| Operating Voltage | 24 V |
Engine
| Engine Model | 6.6L |
|---|---|
| Displacement | 403 in³ |
| Power Measured @ | 2,200 rpm |
| PTO Power | 155.0 hp |
Hydraulic System
| Pump Flow Capacity | 29.0 gal/min |
|---|---|
| Number of Remote Control Valves | 4 |
| Relief Valve Pressure | 2,900 psi |
Dimensions
| Wheelbase | 119 in |
|---|
Transmission
| Max Speed | 32.0 mph |
|---|---|
| Number of Forward Gears | 2 |
| Transmission Type | continuously variable |
Axles
| Final Drive | planetary |
|---|
