Case IH
PATRIOT 4430
Sprayer
18 specifications
1 / 5
Image 1 of 5
Specifications
15 data points
Operating Specifications
| Operating Weight | 8,900 lb |
|---|---|
| Solution Tank Capacity | 999.9 gal |
| Fuel Capacity | 136.0 gal |
Engine
| Engine Model | 6068HF485 |
|---|---|
| Displacement | 415 in³ |
| Gross Power | 225.0 hp |
| Aspiration | Turbocharged |
| Engine Make | John Deere |
| Fuel Type | Diesel |
| Emission Tier Level | Tier 3 |
Dimensions
| Overall Length | 24 in |
|---|---|
| Transport Width | 106 in |
| Transport Height | 83 in |
| Tire Size | 21.5Lx16.1 14 ply ribbed tires |
Boom
| Number of Nozzles - max | 54 |
|---|
