Airman

AX50U-4

Mini Excavator

Operating Weight
10,428 lb
Max Digging Depth
143 in
Net Power
40.0 hp
All mini excavators
Airman AX50U-4 Mini Excavator
1 / 5
Image 1 of 5
Image: machineryline.co.ug

Specifications

20 data points

Operating Specifications

Operating Specifications specifications
Operating Weight10,428 lb
Hydraulic Pump Flow Capacity33.1 gal/min
Hydraulic System Relief Valve Pressure3,481 psi

Engine

Engine specifications
Engine Model4TNV88
Displacement134 in³
Power Measured @2,500 rpm
Net Power40.0 hp
Number of Cylinders4

Dimensions

Dimensions specifications
Ground Clearance13 in
Tail Swing Radius40 in
Width to Outside of Tracks79 in

Undercarriage

Undercarriage specifications
Max Travel Speed2.8 mph
Shoe Size16 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth143 in
Max Reach Along Ground236 in
Max Vertical Wall Digging Depth113 in
Max Loading Height162 in
Shipping Length of Unit216 in
Shipping Height of Unit101 in

Bucket

Bucket specifications
Reference Bucket Capacity0.30 yd³
