AmmannBitelli
RG248
Smooth Drum Roller
22 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 55,843 lb |
|---|---|
| Max Speed | 6.3 mph |
| Fuel Capacity | 107.0 gal |
Engine
| Engine Model | QSB6.7-C220 |
|---|---|
| Net Power | 208.0 hp |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 130 in |
| Wheelbase | 11 in |
| Overall Length | 22 in |
| Overall Width | 100 in |
| Drum Diameter - Front | 67 in |
Tires & Wheels
| Tires | 23.5-25 |
|---|
Drum
| Drum Width | 88 in |
|---|---|
| Drum Diameter | 67 in |
| Vibration Frequency 1 | 28 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 76,435 lb |
| Vibration Frequency 2 | 34 vpm |
| Static Linear Load | 37 lb-ft |
| Centrifugal Force - Low | 103,412 lb |
| Nominal Amplitude - Low | 0 in |
