JCB
VM146D
Smooth Drum Roller
27 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Max Speed | 12.5 mph |
|---|---|
| Fuel Capacity | 47.6 gal |
| Operating Voltage | 12 V |
| Water Spray Tank Fluid Capacity | 277.4 gal |
Engine
| Engine Model | F6L 912 |
|---|---|
| Power Measured @ | 2,500 rpm |
| Net Power | 112.0 hp |
| Aspiration | natural |
Weights
| Operating Weight - standard | 19,290 lb |
|---|---|
| Operating Weight - max ballast | 52,911 lb |
| Average Weight per Wheel - Max Ballast | 6,614 lb |
| Average Weight per Wheel - Standard | 2,412 lb |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Wheelbase | 138 in |
| Overall Length | 15 in |
| Overall Width | 84 in |
| Height - Top of ROPS/FOPS | 130 in |
Tires & Wheels
| Number of Tires - Front | 4 |
|---|---|
| Number of Tires - Rear | 4 |
| Wheel Track/Tire Overlap | 12 in |
| Standard Tire Size | 11.00x20 |
| Oscillation Angle | 6 ° |
