JCB

VM 137 PD

Smooth Drum Roller

Operating Weight
32,077 lb
Drum Width
83 in
All smooth drum rollers
JCB VM 137 PD Smooth Drum Roller
1 / 5
Image 1 of 5
Image: mascus.co.uk

Specifications

37 data points

Operating Specifications

Operating Specifications specifications
Operating Weight32,077 lb
Operating weight ROPS26,786 lb
Operating weight Cabin27,668 lb
Travel Speed6.9 mph
Amplitude0 in
Centrifugal force63,396 lb
Inside Turning Radius133 in
Smooth drum_Static linear load76 lb

Engine

Engine specifications
Engine Model448/EcoMAX
Displacement293 in³
Power Measured @2,200 rpm
Number of Cylinders4
Engine MakeJCB
Stroke5 in
Bore4 in
Torque413 lb-ft
Cooling systemWater
Emissions complianceT4i Stage IIIb
Performance145.0 hp

Dimensions

Dimensions specifications
Ground Clearance18 in
Wheelbase115 in
Overall Width89 in
Height - Top of ROPS/FOPS121 in
Height93 in
front Departure angle46 °
Rear Departure Angle32
Total travel length224 in
Axle to rear face69 in

Fluid Capacities

Fluid Capacities specifications
Fuel Tank75.3 gal
Engine Oil3.7 gal
Hydraulic oil tank19.9 gal
Gear oil2.2 gal

Drum

Drum specifications
Drum Width83 in
Drum thickness1 in

Electrical System

Electrical System specifications
Alternator60
Battery capacity120 Ah
Voltage—
