Ammann

ASC250HD

Smooth Drum Roller

Operating Weight
55,843 lb
Max Speed
6.3 mph
Drum Width
88 in
All smooth drum rollers
Ammann ASC250HD Smooth Drum Roller
1 / 5
Image 1 of 5
Image: lectura-specs.com

Specifications

21 data points

Operating Specifications

Operating Specifications specifications
Operating Weight55,843 lb
Max Speed6.3 mph
Fuel Capacity107.0 gal

Engine

Engine specifications
Engine ModelQSB6.7-C220
Net Power208.0 hp

Dimensions

Dimensions specifications
Ground Clearance20 in
Height - Top of Cab130 in
Wheelbase11 in
Overall Length22 in
Overall Width100 in
Drum Diameter - Front67 in

Tires & Wheels

Tires & Wheels specifications
Tires23.5-25

Drum

Drum specifications
Drum Width88 in
Drum Diameter67 in
Vibration Frequency 128 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High76,435 lb
Vibration Frequency 234 vpm
Static Linear Load37 lb-ft
Centrifugal Force - Low103,412 lb
Nominal Amplitude - Low0 in
