Astra
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Tire Size | 23.5R25 |
|---|
Engine
| Engine Model | Cursor 10 |
|---|---|
| Displacement | 629 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 315.2 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,000 rpm |
| Max Torque | 1,069 lb-ft |
Weights
| Total Empty | 49,031 lb |
|---|
Dimensions
| Overall Length | 396 in |
|---|---|
| Overall Width | 118 in |
| Overall Height | 148 in |
Transmission
| Max Speed | 29.0 mph |
|---|---|
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 3 |
Dump
| Rated Payload | 51,147 lb |
|---|---|
| Raise Time | 13.0 s |
| Lower Time | 13.0 s |
| Capacity - Heaped | 19.00 yd³ |
