ASV

SR-80

Compact Track Loader

Operating Weight
8,972 lb
Max Speed - high range
12.5 mph
Displacement
201 in³
Gross Power
80.5 hp
All compact track loaders
ASV SR-80 Compact Track Loader
1 / 5
Image 1 of 5
Image: asvaus.com

Specifications

28 data points

Operating Specifications

Operating Specifications specifications
Operating Weight8,972 lb
Max Speed - high range12.5 mph
Max Speed - low range7.0 mph
Fuel Capacity18.0 gal
Hydraulic System Fluid Capacity21.0 gal

Engine

Engine specifications
Engine Model804C-33T
Displacement201 in³
Power Measured @2,600 rpm
Gross Power80.5 hp
Net Power78.0 hp
Number of Cylinders4
AspirationTurbocharged
Peak Torque186 lb-ft

Hydraulic System

Hydraulic System specifications
Pump Flow30.0 gal/min
Relief Valve Pressure3,000 psi

Dimensions

Dimensions specifications
Ground Clearance15 in
Height - Top of Cab86 in
Reach at Max Lift and Dump20 in
Width Over Tracks73 in
Length with Bucket143 in
Clearance at Max Lift and Dump98 in
Length - without Bucket113 in

Undercarriage

Undercarriage specifications
Ground Pressure3 psi
Length of Track on Ground72 in
Width of Track20 in
Ground Contact Area2,840 in³

Loader

Loader specifications
Tipping Angle6,200 °
Operating Load3,100 lb
