Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Fuel Capacity | 36.0 gal |
|---|---|
| Max Weight | 17,617 lb |
Engine
| Engine Model | 4045T |
|---|---|
| Gross Power | 84.5 hp |
| Aspiration | turbocharged |
Hydraulic System
| Pump Flow Capacity | 42.3 gal/min |
|---|---|
| Relief Valve Pressure | 3,626 psi |
| Pump Type | gear type tandem with unloader |
Dimensions
| Transport Width | 86 in |
|---|---|
| Transport Length | 282 in |
Transmission
| Max Speed | 20.6 mph |
|---|---|
| Max Speed - Reverse | 20.6 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | powershift |
Backhoe
| Dig Depth | 173 in |
|---|---|
| Reach From Swivel | 220 in |
| Bucket Dig Force | 11,982 lb |
| Load Height | 135 in |
Loader
| Bucket Capacity | 1.40 yd³ |
|---|---|
| Lift Capacity | 11,389 lb |
| Clearance at Max Dump Height | 104 in |
| Bucket Width | 92 in |
