Caterpillar
613C Series II
Scraper
84 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 46,244 lb |
|---|---|
| Fuel Capacity | 128.2 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 100 A |
Engine
| Engine Model | OM501LA |
|---|---|
| Displacement | 729 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 413.1 hp |
| Aspiration | Turbocharged |
| Engine Make | Mercedes Benz |
Hydraulic System
| Pump Flow Capacity | 79.3 gal/min |
|---|---|
| Relief Valve Pressure | 117 psi |
Dimensions
| Ground Clearance | 23 in |
|---|---|
| Height - Top of Cab | 148 in |
| Wheelbase | 145 in |
| Overall Length | 279 in |
| Width Outside Frame | 145 in |
Transmission
| Max Speed - Forward | 24.3 mph |
|---|---|
| Max Speed - Reverse | 3.5 mph |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 1 |
