Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Fuel Capacity | 127.9 gal |
|---|---|
| Tire Size | 23.5R25 |
Engine
| Engine Model | OM906LA |
|---|---|
| Gross Power | 290.0 hp |
| Max Torque | 1,364 lb-ft |
Weights
| Total Empty | 3,968 lb |
|---|---|
| Total Loaded | 60,186 lb |
Dimensions
| Overall Length | 377 in |
|---|---|
| Overall Width | 119 in |
| Overall Height | 135 in |
Transmission
| Max Speed | 33.0 mph |
|---|---|
| Transmission Type | ZF HP592 |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 1 |
Dump
| Dump Angle | 70 ° |
|---|---|
| Raise Time | 12.0 s |
| Lower Time | 6.0 s |
| Capacity - Heaped | 21.59 yd³ |
| Capacity - Struck | 16.49 yd³ |
