Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Fuel Capacity | 127.9 gal |
|---|---|
| Tire Size | 29.5R25 |
Engine
| Gross Power | 290.0 hp |
|---|---|
| Max Torque | 1,364 lb-ft |
| Make | Mercedes Benz |
Weights
| Total Empty | 58,919 lb |
|---|---|
| Total Loaded | 71,650 lb |
Dimensions
| Overall Length | 404 in |
|---|---|
| Overall Width | 128 in |
| Overall Height | 149 in |
Transmission
| Max Speed | 33.9 mph |
|---|---|
| Transmission Type | Allison HD4560 |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 1 |
Drive System
| Drive Config | 6x6 |
|---|
Articulating/Rigid
| Articulating/Rigid | Articulated |
|---|
Dump
| Dump Angle | 70 ° |
|---|---|
| Raise Time | 13.0 s |
| Lower Time | 7.6 s |
| Capacity - Heaped | 26.20 yd³ |
| Capacity - Struck | 19.89 yd³ |
