Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Fuel Capacity | 127.9 gal |
|---|---|
| Tire Size | 26.5R25 |
Engine
| Engine Model | OM501LA |
|---|---|
| Gross Power | 315.0 hp |
| Max Torque | 1,475 lb-ft |
Weights
| Total Empty | 61,699 lb |
|---|---|
| Total Loaded | 7,937 lb |
Dimensions
| Overall Length | 415 in |
|---|---|
| Overall Width | 127 in |
| Overall Height | 151 in |
Transmission
| Max Speed | 39.2 mph |
|---|---|
| Transmission Type | Allison HD4560 |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 1 |
Dump
| Dump Angle | 70 ° |
|---|---|
| Raise Time | 13.0 s |
| Lower Time | 7.6 s |
| Capacity - Heaped | 29.49 yd³ |
| Capacity - Struck | 22.20 yd³ |
