New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
16 data points
Operating Specifications
| Operating Weight | 22,575 lb |
|---|---|
| Fuel Capacity | 52.9 gal |
| Tire Size | 17.5x25 |
| Static Tipping Weight | 18,285 lb |
Engine
| Engine Model | 6068TF250 |
|---|---|
| Net Power | 116.7 hp |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 127 in |
| Wheelbase | 119 in |
| Reach at Max Lift and Dump | 30 in |
| Length with Bucket on Ground | 272 in |
Transmission
| Transmission Type | countershaft |
|---|
Bucket
| Bucket Capacity - heaped | 2.50 yd³ |
|---|---|
| Dump Clearance at Max Raise | 114 in |
| Breakout Force | 26,752 lb |
| Bucket Width | 101 in |
