Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
15 data points
Operating Specifications
| Operating Weight | 29,101 lb |
|---|---|
| Fuel Capacity | 58.2 gal |
| Tire Size | 20.5x25 |
| Static Tipping Weight | 22,955 lb |
Engine
| Engine Model | e 6068TF250 |
|---|---|
| Net Power | 161.0 hp |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 134 in |
| Wheelbase | 119 in |
| Reach at Max Lift and Dump | 35 in |
| Length with Bucket on Ground | 292 in |
Transmission
| Transmission Type | ZF 4WG160 counterhsaft |
|---|
Bucket
| Bucket Capacity - heaped | 3.20 yd³ |
|---|---|
| Dump Clearance at Max Raise | 119 in |
| Breakout Force | 36,869 lb |
