Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 4,999 lb |
|---|---|
| Fuel Capacity | 13.8 gal |
| Hydraulic System Fluid Capacity | 14.6 gal |
| Tire Size | 10 x 16.5 |
Engine
| Engine Model | 104-22 |
|---|---|
| Displacement | 135 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 48.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Natural |
Hydraulic System
| Pump Flow Capacity | 15.9 gal/min |
|---|---|
| Relief Valve Pressure | 2,842 psi |
Dimensions
| Ground Clearance | 10 in |
|---|---|
| Height - Top of Cab | 78 in |
| Wheelbase | 36 in |
| Width Over Tires | 59 in |
| Reach at Max Lift and Dump | 21 in |
| Length with Bucket | 120 in |
| Clearance at Max Lift and Dump | 90 in |
| Turning Radius from Center - inc bucket | 70 in |
| Turning Radius from Center - machine rear | 44 in |
| Length w/o Bucket | 95 in |
Loader
| Bucket Capacity | 0.50 yd³ |
|---|---|
| Operating Load Rating | 1,378 lb |
| Tipping Angle | 2,756 ° |
| Breakout Force | 3,616 psi |
