Specifications
54 data points
Operating Specifications
| Operating Weight | 3,535 lb |
|---|---|
| Max Speed | 7.6 mph |
| Fuel Capacity | 23.8 gal |
| Hydraulic System Fluid Capacity | 14.1 gal |
| Operating Speed | 7.6 mph |
| Breakout Force - Tilt Cylinder | 5,212 lb |
| Rated Operating Capacity | 2,250 lb |
| Tipping Load | 4,500 lb |
| Rated Operating Capacity with Optional Counterweight | 2,300 lb |
| Breakout Force - Lift Cylinder | 5,020 lb |
Engine
| Engine Model | Cat 3034C |
|---|---|
| Displacement | 183 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 59.0 hp |
| Number of Cylinders | 4 |
| Engine Make | Caterpillar |
| Stroke | 4 in |
| Bore | 4 in |
| Net Flywheel Power | 59.0 hp |
Weights
| Operating Weight | 7,615 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 22.0 gal/min |
|---|---|
| Loader Hydraulic Pressure | 3,300 psi |
| Loader Hydraulic Flow | 22.0 gal/min |
| Hydraulic Flow | Standard flow |
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Wheelbase | 49 in |
| Width Over Tires | 73 in |
| Reach at Max Lift and Dump | 31 in |
| Length with Bucket on Ground | 142 in |
| Length with Bucket | 143 in |
| Clearance at Max Lift and Dump | 96 in |
| Turning Radius from Center - inc bucket | 89 in |
| Length w/o Bucket | 115 in |
| Length - without Bucket | 114 in |
| Wheel Base | 49 in |
| Bucket Pin Height - Maximum Lift | 128 in |
| Bucket Pin Height - Carry Position | 10 in |
| Clearance at Maximum Lift and Dump | 98 in |
| Maximum Overall Height | 161 in |
| Reach - Maximum Lift/Dump | 33 in |
| Vehicle Width over Tires | 72 in |
| Bumper Overhang - Rear Axle | 41 in |
Cab & Operator
| FOPS | SAEJ/ISO 3449 APR98 Level I and ISO3449:1992 Level I |
|---|---|
| ROPS | SAE J1040 MAY94 and ISO3471:1994 |
| FOPS Level II | SAEJ/ISO 3449 APR 98 Level II and ISO 3449:1992 Level II (optional) |
Loader
| Bucket Capacity | 0.60 yd³ |
|---|---|
| Operating Load Rating | 2,250 lb |
| Tipping Angle | 4,733 ° |
Service Refill Capacities
| Cooling System | 2.6 gal |
|---|---|
| Hydraulic Tank | 9.2 gal |
| Fuel Tank | 23.8 gal |
| Chain Box - Each Side | 2.1 gal |
| Engine Crankcase | 1.8 gal |
| Hydraulic System | 14.0 gal |
