Hyundai
Thomas
85
Skid Steer Loader
26 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 2,350 lb |
|---|---|
| Max Speed | 4.5 mph |
| Max Speed - high range | 4.5 mph |
| Fuel Capacity | 8.2 gal |
| Hydraulic System Fluid Capacity | 11.1 gal |
Engine
| Engine Model | D1105 |
|---|---|
| Power Measured @ | 3,000 rpm |
| Gross Power | 25.0 hp |
Hydraulic System
| Pump Flow Capacity | 8.6 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
| Pump Flow | 8.6 gal/min |
Dimensions
| Ground Clearance | 6 in |
|---|---|
| Height - Top of Cab | 52 in |
| Wheelbase | 31 in |
| Width Over Tires | 43 in |
| Reach at Max Lift and Dump | 11 in |
| Width Over Tracks | 43 in |
| Length with Bucket | 80 in |
| Clearance at Max Lift and Dump | 47 in |
| Turning Radius from Center - inc bucket | 50 in |
| Turning Radius from Center - machine rear | 38 in |
| Length w/o Bucket | 64 in |
| Length - without Bucket | 64 in |
Loader
| Operating Load Rating | 420 lb |
|---|---|
| Tipping Angle | 1,199 ° |
| Operating Load | 421 lb |
