Thomas
Caterpillar
252
Skid Steer Loader
54 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 2,983 lb |
|---|---|
| Max Speed | 5.0 mph |
| Fuel Capacity | 14.6 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
Engine
| Engine Model | D722B |
|---|---|
| Displacement | 44 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 19.8 hp |
| Number of Cylinders | 3 |
Hydraulic System
| Pump Flow Capacity | 8.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,100 psi |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Height - Top of Cab | 72 in |
| Wheelbase | 33 in |
| Width Over Tires | 36 in |
| Reach at Max Lift and Dump | 15 in |
| Length with Bucket | 106 in |
| Clearance at Max Lift and Dump | 70 in |
| Turning Radius from Center - inc bucket | 60 in |
| Turning Radius from Center - machine rear | 38 in |
| Length w/o Bucket | 84 in |
Loader
| Bucket Capacity | 0.30 yd³ |
|---|---|
| Operating Load Rating | 850 lb |
| Tipping Angle | 1,800 ° |
| Breakout Force | 2,200 psi |
