Gehl
Caterpillar
252
Skid Steer Loader
54 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Engine
| Engine Model | 3TNV82BPMS |
|---|---|
| Displacement | 81 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 24.0 hp |
| Torque Measured @ | 1,200 rpm |
| Max Torque | 68 lb-ft |
Dimensions
| Ground Clearance | 6 in |
|---|---|
| Height - Top of Cab | 76 in |
| Wheelbase | 31 in |
| Width Over Tires | 36 in |
| Reach at Max Lift and Dump | 15 in |
| Length with Bucket | 102 in |
| Clearance at Max Lift and Dump | 73 in |
| Turning Radius from Center - inc bucket | 58 in |
| Turning Radius from Center - machine rear | 43 in |
| Length w/o Bucket | 76 in |
Loader
| Operating Width | 36 in |
|---|
Hydraulic
| Pump Flow Capacity | 10.1 gal/min |
|---|---|
| Relief Valve Pressure | 2,255 psi |
Operational
| Operating Weight | 2,981 lb |
|---|---|
| Fuel Capacity | 7.7 gal |
| Hydraulic System Fluid Capacity | 7.2 gal |
| Operating Speed | 5.5 mph |
