John Deere
Bobcat
773
Skid Steer Loader
17 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 4,360 lb |
|---|---|
| Max Speed | 6.5 mph |
| Fuel Capacity | 12.0 gal |
| Operating Voltage | 12 V |
| Operating Speed | 6.5 mph |
Engine
| Engine Model | Series 220 |
|---|---|
| Displacement | 91 in³ |
| Power Measured @ | 3,000 rpm |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 11.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,650 psi |
| Pump Type | Open-center |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 73 in |
| Wheelbase | 374 in |
| Reach at Max Lift and Dump | 20 in |
| Length with Bucket | 121 in |
| Clearance at Max Lift and Dump | 89 in |
| Turning Radius from Center - machine rear | 45 in |
| Length w/o Bucket | 97 in |
Loader
| Bucket Capacity | 0.50 yd³ |
|---|---|
| Operating Load Rating | 1,250 lb |
| Tipping Angle | 1,450 ° |
| Breakout Force | 2,600 psi |
