John Deere
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Engine
| Engine Model | C190 |
|---|---|
| Displacement | 119 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 40.0 hp |
| Number of Cylinders | 4 |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Height - Top of Cab | 83 in |
| Wheelbase | 36 in |
| Width Over Tires | 60 in |
| Reach at Max Lift and Dump | 20 in |
| Length with Bucket | 119 in |
| Clearance at Max Lift and Dump | 78 in |
| Turning Radius from Center - inc bucket | 51 in |
| Turning Radius from Center - machine rear | 51 in |
| Length w/o Bucket | 91 in |
Loader
| Bucket Capacity | 0.50 yd³ |
|---|---|
| Operating Load Rating | 1,410 lb |
| Tipping Angle | 2,820 ° |
Hydraulic
| Pump Flow Capacity | 15.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,000 psi |
| Pump Type | Open-center |
Operational
| Operating Weight | 5,470 lb |
|---|---|
| Max Speed | 6.1 mph |
| Fuel Capacity | 15.0 gal |
| Hydraulic System Fluid Capacity | 18.0 gal |
| Operating Voltage | 12 V |
| Tire Size | 10-16.56PR flotation |
| Operating Speed | 6.1 mph |
| Cooling System Fluid Capacity | 3.1 gal |
