Ingersoll Rand
PF150
Asphalt Paver
19 specifications
Bitelli
BB740
- Operating Weight w/ Screed
- 25,353 lb
- Paving Width - max
- 221 in
- Gross Power
- 82.5 hp
- Length w/ Screed
- 222 in
1 / 5
Image 1 of 5
Specifications
16 data points
Operating Specifications
| Operating Weight w/ Screed | 25,353 lb |
|---|---|
| Operating Weight w/o Screed | 18,960 lb |
| Fuel Capacity | 34.4 gal |
| Hydraulic System Fluid Capacity | 31.8 gal |
Engine
| Engine Model | 3054 DINA |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 82.5 hp |
Dimensions
| Transport Width | 100 in |
|---|---|
| Transport Height | 115 in |
| Length w/ Screed | 222 in |
| Width w/ Hopper Open | 124 in |
Hopper/Paver
| Paving Width - max | 221 in |
|---|---|
| Paving Speed - max | 2.2 mph |
| Hopper Capacity | 7 lb |
| Travel Speed - max | 8.4 mph |
| Auger Diameter | 14 in |
