BOMAG
Dynapac
F5CS
Asphalt Paver
17 specifications
BOMAG
BF 4413
- Operating Weight w/ Screed
- 15,500 lb
- Paving Width - max
- 158 in
- Gross Power
- 60.0 hp
- Length w/ Screed
- 146 in
1 / 5
Image 1 of 5
Specifications
16 data points
Operating Specifications
| Operating Weight w/ Screed | 15,500 lb |
|---|---|
| Fuel Capacity | 23.3 gal |
| Hydraulic System Fluid Capacity | 27.7 gal |
| Cooling System Fluid Capacity | 3.1 gal |
Engine
| Gross Power | 60.0 hp |
|---|---|
| Make | Cummins |
Dimensions
| Transport Width | 103 in |
|---|---|
| Transport Height | 80 in |
| Track Width | 12 in |
| Length w/ Screed | 146 in |
| Length w/o Screed | 138 in |
Hopper/Paver
| Paving Width - max | 158 in |
|---|---|
| Hopper Capacity | 7 lb |
| Travel Speed - max | 4.2 mph |
| Paving Thickness - max | 6 in |
| Paving Speed | 0.0 – 4.1 mph |
