Bobcat
JCB
8010 CTS
Mini Excavator
34 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 3,525 lb |
|---|---|
| Fuel Capacity | 7.3 gal |
| Hydraulic Pump Flow Capacity | 15.9 gal/min |
Engine
| Engine Model | D722-EB |
|---|---|
| Displacement | 44 in³ |
| Power Measured @ | 3,000 rpm |
| Net Power | 15.7 hp |
Dimensions
| Height - Top of Cab | 88 in |
|---|---|
| Length of Track on Ground | 44 in |
| Tail Swing Radius | 43 in |
| Width to Outside of Tracks | 40 in |
| Removal Counterweight Clearance | 18 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 30 in |
| Max Travel Speed | 1.9 mph |
| Shoe Size | 9 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 88 in |
|---|---|
| Max Reach Along Ground | 151 in |
| Max Vertical Wall Digging Depth | 62 in |
| Max Loading Height | 98 in |
| Shipping Length of Unit | 154 in |
| Max Cutting Height | 138 in |
| Shipping Height of Unit | 88 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Comparable machines
Other mini excavators in a similar weight class.
