EC13XTV
Mini Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 2,447 lb |
|---|---|
| Fuel Capacity | 3.1 gal |
| Hydraulic Pump Flow Capacity | 4.3 gal/min |
| Hydraulic System Fluid Capacity | 5.6 gal |
| Engine Oil Capacity | 0.8 gal |
Engine
| Engine Model | 403D-11 |
|---|---|
| Displacement | 69,018 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 18.6 hp |
| Alternator | 15 A |
| Cooling system | Water cooled |
Hydraulic System
| Auxiliary hydraulic flow | 6.4 gal/min |
|---|---|
| Pump Type | 3 section gear |
| Excavator/track main relief | 2,611 psi |
| Nominal output | 3.2 gal/min |
| Slew main relief | — |
Dimensions
| Overall Length | 118 in |
|---|---|
| Tail Swing Radius | 36 in |
| Width Over Tracks | 28 in |
| Undercarriage Overall Length | 49 in |
Undercarriage
| Number of Track Rollers per Side | 3 |
|---|---|
| Drawbar Pull | 2,023 lb |
| Track tension | Grease |
Boom/Stick Excavator Option 1
| Max Reach Along Ground | 122 in |
|---|---|
| Max.Dumping Height | 71 in |
| Max Digging Height | 103 in |
| Maximum digging depth - dozer up | 76 in |
| Maximum vertical wallcut depth | 64 in |
Boom
| Boom swing left | 70 ° |
|---|---|
| Boom swing right | 70 ° |
| Bucket rotation | 201 ° |
| Bucket tearout | 2,091 lb |
| Dipper tearout | 1,034 lb |
Performance
| Gradeability | 35.0 % |
|---|
