Bobcat
T300
- Operating Weight
- 9,702 lb
- Max Speed - high range
- 6.6 mph
- Displacement
- 201 in³
- Gross Power
- 81.0 hp
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 9,702 lb |
|---|---|
| Max Speed - high range | 6.6 mph |
| Fuel Capacity | 30.0 gal |
Engine
| Engine Model | V3300TE |
|---|---|
| Displacement | 201 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 81.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
Hydraulic System
| Pump Flow | 21.2 gal/min |
|---|---|
| Relief Valve Pressure | 3,300 psi |
Dimensions
| Height - Top of Cab | 81 in |
|---|---|
| Reach at Max Lift and Dump | 35 in |
| Width Over Tracks | 78 in |
| Length with Bucket | 144 in |
| Clearance at Max Lift and Dump | 100 in |
| Turning Radius from Center - inc bucket | 84 in |
| Length - without Bucket | 115 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Length of Track on Ground | 65 in |
| Width of Track | 18 in |
| Number of Track Rollers per Side | 5 |
| Track Gauge | 61 in |
Loader
| Bucket Capacity | 0.60 yd³ |
|---|---|
| Tipping Angle | 9,208 ° |
| Operating Load | 3,000 lb |
