Bobcat
ASV
PT-70
Compact Track Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 8,555 lb |
|---|---|
| Max Speed - low range | 6.6 mph |
| Fuel Capacity | 27.3 gal |
| Cooling System Fluid Capacity | 3.0 gal |
| Travel Speed | 6.2 mph |
Engine
| Gross Power | 74.3 hp |
|---|---|
| Aspiration | Turbocharged |
| Emission Tier Level | Tier 4 |
| Fuel | Diesel |
| Horsepower - Gross | 74.0 hp |
Hydraulic System
| Pump Flow | 23.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,500 psi |
Dimensions
| Height - Top of Cab | 81 in |
|---|---|
| Overall Width | 73 in |
| Reach at Max Lift and Dump | 25 in |
| Width Over Tracks | 73 in |
| Overall Height | 81 in |
| Length with Bucket | 137 in |
| Turning Radius from Center - machine rear | 88 in |
| Length - without Bucket | 109 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Length of Track on Ground | 702 in |
| Width of Track | 13 in |
General Specifications
| Operating Width IN. (CM) | 72.9 (185.2) Starting 2019 Model Year |
|---|---|
| Engine Power HP (KW) | 74 (55.2) Starting 2019 Model Year |
| OPERATING LOAD LBS. (KG) | 2,100 (953) Starting 2019 Model Year |
| Rated Operating Capacity LBS (KG) 50% | 2,100 (953) Starting 2020 Model Year |
Loader
| Tipping Angle | 6,000 ° |
|---|---|
| Operating Load | 2,100 lb |
| Operating Width | 74 in |
