Bobcat
ASV
PT-70
Compact Track Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 10,327 lb |
|---|---|
| Max Speed - high range | 10.7 mph |
| Max Speed - low range | 6.6 mph |
| Fuel Capacity | 27.2 gal |
Engine
| Gross Power | 92.0 hp |
|---|---|
| Net Power | 92.0 hp |
| Aspiration | Turbocharged |
| Emission Tier Level | Tier 4 |
| Fuel | Diesel |
Hydraulic System
| Pump Flow | 23.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,500 psi |
Dimensions
| Height - Top of Cab | 81 in |
|---|---|
| Reach at Max Lift and Dump | 35 in |
| Width Over Tracks | 79 in |
| Length with Bucket | 142 in |
| Turning Radius from Center - machine rear | 88 in |
| Length - without Bucket | 114 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Length of Track on Ground | 65 in |
| Width of Track | 18 in |
General Specifications
| Operating Width IN. (CM) | 80 (203.2) Starting 2026 Model Year |
|---|---|
| Engine Power HP (KW) | 92 (68.6) Starting 2019 Model Year |
| OPERATING LOAD LBS. (KG) | 3,475 (1,576) Starting 2019 Model Year |
| Rated Operating Capacity LBS (KG) 50% | 3,475 (1,576) Starting 2020 Model Year |
| Narrow Track Operating Width IN. (CM)Roller or Torsion Suspension | NA Starting 2022 Model Year |
| Wide Track Operating Width IN. (CM)Roller or Torsion Suspension | 78 (198.1) Starting 2022 Model Year |
| Wide Track Operating Width IN. (CM) | 78 (198.1) Starting 2022 Model Year |
Loader
| Tipping Angle | 9,929 ° |
|---|---|
| Operating Load | 3,475 lb |
| Operating Width | 80 in |
| Bucket Width | 80 in |
