BOMAG
Dynapac
PL2000S
Cold Planer
19 specifications
BOMAG
BM 2000/50
- Operating Weight - Full Load
- 65,257 lb
- Cutting Width
- 79 in
- Displacement
- 976 in³
- Gross Power
- 469.0 hp
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight - Full Load | 65,257 lb |
|---|---|
| Operating Speed | 1.3 mph |
| Travel Speed | 3.3 mph |
| Fuel Capacity | 211.4 gal |
| Water Spray System Fluid Capacity | 713.2 gal |
| Shipping Weight - Empty | 57,761 lb |
| Hydraulic System Fluid Capacity | 60.8 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 A |
Engine
| Engine Model | TCD2015 |
|---|---|
| Displacement | 976 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 469.0 hp |
| Number of Cylinders | 8 |
Dimensions
| Shipping Height | 119 in |
|---|---|
| Shipping Length | 457 in |
| Shipping Width | 100 in |
| Operating Length | 574 in |
| Max Operating Height | 178 in |
Track
| Number of Track Units | 4 |
|---|---|
| Front Track Width | 10 in |
| Rear Track Width | 10 in |
| Front Track Length | 65 in |
| Rear Track Length | 65 in |
Conveyor System
| Discharge Conveyor Width | 32 in |
|---|---|
| Collecting Conveyor Width | 32 in |
Rotary Cutter
| Cutting Width | 79 in |
|---|---|
| Cutting Depth | 13 in |
| Number of Tools | 168 |
| Tool Spacing | 1 in |
| Cutter Diameter | 42 in |
