BOMAG

BW 161 AD-5

Smooth Drum Roller

Drum Width
66 in
Gross Power
114.0 hp
All smooth drum rollers
BOMAG BW 161 AD-5 Smooth Drum Roller
1 / 5
Image 1 of 5
Image: power-equip.com

Specifications

34 data points

Operating Specifications

Operating Specifications specifications
Operating weight ROPS21,600 lb
Operating weight Cabin22,045 lb
Fuel Capacity38.3 gal
Operating Voltage12 V
Water Spray Tank Fluid Capacity198.1 gal

Engine

Engine specifications
Power Measured @2,600 rpm
Gross Power114.0 hp
Number of Cylinders4
Engine MakeKubota
Fuel TypeDiesel
Engine TypeV3800 CR-TI
Emissions CertificationTier 4i
Cooling methodWater

Weights

Weights specifications
Grossweight8,800 lb
Front axle weight3,550 lb
Rear axle weight3,750 lb
Static linear load, front20 lb-ft
Static linear load, rear21 lb-ft

Dimensions

Dimensions specifications
Ground Clearance10 in
Height - Top of Cab121 in
Wheelbase143 in
Overall Length191 in
Overall Width73 in
Track radius inner193 in

Brakes & Steering

Brakes & Steering specifications
Service brakeHydrostatic
Parking brakeMulti disc

Drum

Drum specifications
Drum Width66 in
Drum Diameter48 in
Vibration Frequency 150 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High19,109 lb
Vibration Frequency 270 vpm
Frequency45 vpm

Steering System

Steering System specifications
SystemOscil.artic
