BOMAG

CR 352 L

Asphalt Paver

Paving Width - max
240 in
Gross Power
160.0 hp
Length w/ Screed
96 in
All asphalt pavers
BOMAG CR 352 L Asphalt Paver
1 / 5
Image 1 of 5
Image: power-equip.com

Specifications

43 data points

Operating Specifications

Operating Specifications specifications
Operating Weight31,870 lb
Fuel Capacity62.0 gal
Hydraulic System Fluid Capacity50.0 gal
Operating Voltage12 V
Cooling System Fluid Capacity6.0 gal

Engine

Engine specifications
Engine ModelQSB4.5
Power Measured @2,200 rpm
Gross Power160.0 hp
AspirationTurbocharged
Engine MakeCummins
MakeCummins
Emission Tier LevelTier 3

Weights

Weights specifications
Tractor Weight25,260 lb
Tractor Weight - with Fastach 8 and hydroflated tires28,760 lb
Tractor Weight - with Stretch 16 and hydroflated tires31,870 lb

Dimensions

Dimensions specifications
Overall Length445 in
Transport Width840 in
Track Width34 in
Length w/ Screed96 in

Brakes & Steering

Brakes & Steering specifications
Parking brakeMultiple disc

Tires & Wheels

Tires & Wheels specifications
Drive Tires26.00 in (66.04 cm)
Front Wheels22 in

Hopper/Paver

Hopper/Paver specifications
Paving Width - max240 in
Paving Speed - max5.2 mph
Hopper Capacity20,000 lb
Travel Speed - max13.0 mph
Auger Diameter13 in
Hopper Length70 in
Auger ConstructionCast High alloy
Auger Thickness1 in
Feed Tunnel Width25 in
Hopper Volume5.90 yd³
Hopper Width118 in
Paving Depth - max12 in
Slat Conveyor Liner Thickness0 in

Screed

Screed specifications
Fastach 8 (electric heat) generator26.9 hp
Fastach 8 (two oil heaters) 178,000 BTU1.3 gph
Negative crown1 in
Positive crown3 in
Screed plate thickness1 in
Stretch 16 (four oil heaters) 274,000 BTU (total)2.0 gph
Stretchà ® 16 (electric heat) generator26.9 hp
Vibrations per minute (max)3,000
