BOMAG
CR 662 RM
Asphalt Paver
37 specifications
Marini
MF1007
- Operating Weight w/ Screed
- 40,345 lb
- Paving Width - max
- 500 in
- Gross Power
- 178.4 hp
- Length w/ Screed
- 233 in
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight w/ Screed | 40,345 lb |
|---|---|
| Fuel Capacity | 66.1 gal |
| Hydraulic System Fluid Capacity | 50.2 gal |
Engine
| Engine Model | BF6M1013 |
|---|---|
| Power Measured @ | 2,300 rpm |
| Gross Power | 178.4 hp |
| Number of Cylinders | 6 |
Dimensions
| Length of Track on Ground | 115 in |
|---|---|
| Transport Width | 100 in |
| Transport Height | 142 in |
| Track Width | 14 in |
| Length w/ Screed | 233 in |
| Width w/ Hopper Open | 132 in |
Hopper/Paver
| Paving Width - max | 500 in |
|---|---|
| Paving Speed - max | 0.8 mph |
| Hopper Capacity | 9 lb |
| Travel Speed - max | 2.8 mph |
| Auger Diameter | 16 in |
| Paving Thickness - max | 12 in |
